Winter storm 12/8-9 model discussion part II


Ji

Recommended Posts

  • Replies 994
  • Created
  • Last Reply

ANyone thinking of fog,  looks like it sure would be to me.  I'm with Matt, there will be a warm layer.  I suspect it will be more agressive than on the GFS but that's a guess and I may be prejudiced based on the old versions that tended to have a slight cold bias near 850.  Does anyone see Euro sounding in as much detail as the NAM or GFS sounding?

Link to comment
Share on other sites

soundings in mby at 45 hrs; my guess is sleet in light of a 2000+ meter layer of sub-freezing air below warm layer, much of which is -5C

mets agree...disagree?

1024.    51.   -1.9   -2.7    53.8     3.8 1000.   243.   -3.9   -4.0    60.1     6.2  975.   443.   -4.8   -5.0    77.5     7.4  950.   647.   -4.8   -5.0    94.9     5.9  925.   857.   -5.3   -5.6   110.0     6.0  900.  1072.   -5.3   -5.4   126.2     6.9  875.  1294.   -3.8   -3.8   147.7     7.3  850.  1523.   -2.8   -2.8   178.7     9.4  825.  1761.   -0.8   -0.8   199.0    17.9  800.  2007.   -0.2   -0.1   208.4    23.3  775.  2262.    1.1    1.2   223.4    24.1  750.  2526.    1.4    1.4   239.2    26.5  725.  2799.    0.7    0.6   248.2    30.4  700.  3081.   -0.3   -0.3   251.9    34.1  650.  3672.   -2.6   -2.8   252.8    37.9  600.  4303.   -5.8   -6.3   252.9    39.3
Link to comment
Share on other sites



soundings in mby at 45 hrs; my guess is sleet in light of a 2000+ meter layer of cold air below warm layer, much of which is -5C

mets agree...disagree?

1024.    51.   -1.9   -2.7    53.8     3.8 1000.   243.   -3.9   -4.0    60.1     6.2  975.   443.   -4.8   -5.0    77.5     7.4  950.   647.   -4.8   -5.0    94.9     5.9  925.   857.   -5.3   -5.6   110.0     6.0  900.  1072.   -5.3   -5.4   126.2     6.9  875.  1294.   -3.8   -3.8   147.7     7.3  850.  1523.   -2.8   -2.8   178.7     9.4  825.  1761.   -0.8   -0.8   199.0    17.9  800.  2007.   -0.2   -0.1   208.4    23.3  775.  2262.    1.1    1.2   223.4    24.1  750.  2526.    1.4    1.4   239.2    26.5  725.  2799.    0.7    0.6   248.2    30.4  700.  3081.   -0.3   -0.3   251.9    34.1  650.  3672.   -2.6   -2.8   252.8    37.9  600.  4303.   -5.8   -6.3   252.9    39.3

It's pretty doubtfull anything would still be liquid when the warm layer is above is above 850mb and 975mb is -5 C. Usually 900mb is warm in ZR periods.

Link to comment
Share on other sites

While I was playing around with wundermap I found sounding profiles based on geography! When you are in a model click the small H/L symbol in the top right corner of the wundermap to plot skew-T's. The sounding even updates in real time as you move across the map, pretty neat tool. Shared images of the soundings are blocked though.

Link to comment
Share on other sites
